Hot Dip Galvanizing
Long-Term Protection
Hot Dip Galvanizing offers you long-term protection against rust and corrosion of steel products, and with 150 years experience Wedge Group Galvanizing can offer you high quality galvanizing and unrivalled customer service.
What is Hot Dip Galvanising?
Hot dip galvanizing (or hot dip coating) is a process developed to prevent steel from corroding. Before the process can take place, the steel goes through a thorough chemical clean which removes all rust, oil and mill scale from the surface. When the cleaning solution has been rinsed off, the coating process can begin. The steel is dipped into a bath of molten zinc heated to around 450°C (860°F) before being left to cool in a quench tank. When the cooling process is complete, the zinc coating is then metallurgically bonded to the steel.
Hot dip zinc plating protects the underlying steel from exposure to corrosion from moisture, oxygen, and chemicals. It significantly extends the lifespan of the coated metal, even in the harshest environments.
Design Criteria
The galvanizing process should not be viewed in isolation but must be considered at the design stage.
Some parts may need extra venting or drainage points and, in the case of internal tread forms, a post-galvanizing operation will be necessary. If certain areas of the steel need to be left uncoated, these areas need to be properly masked before the galvanizing process. We offer free advice and guidance on best design practices to give you the best quality galvanizing.
What we can offer:
- Collection and delivery service
- Direct-to-site deliveries
- 24-hour turnaround service on request
- Unrivalled customer service
- Spin galvanizing
- Shot blasting/powder coating*
- Double Dip: Up to 29m
- Vertical Dip: Up to 3.2m
- ISO 9001 quality approved
- Technical and design advice
*These options are carried out by a third party. Please contact your nearest plant for more details
FAQs
Hot dip galvanized steel will last very well in most environments. It is not uncommon for galvanized steel to last more than 70 years under certain conditions. Latest corrosion rates can be found at the Galvanizers Association
The three intermetallic layers that form during the galvanizing process are all harder than the substrate steel and have excellent abrasion resistance.
“White Rust”, or wet storage stain, is formed because zinc on newly-galvanized steel is very reactive and quickly forms zinc oxide and zinc hydroxide corrosion products that go on to become the stable zinc carbonate.
When galvanized steel is stacked damp, stored in wet boxes or shrink wrapped with no free-flowing air, the zinc forms excessive layers of zinc hydroxide, otherwise known as wet storage stain.
Most wet storage stain can be easily removed with a nylon brush. To prevent wet storage stain, store galvanized steel indoors and in such a way to allow free-flowing air between each galvanized item.
